ATO-W4-14S Screw Feeding Multihead Weigher

ATO W4 14S Screw Feeding Multihead Weigher
ATO W4 14S Screw Feeding Multihead Weigher p1
ATO W4 14S Screw Feeding Multihead Weigher p2
ATO W4 14S Screw Feeding Multihead Weigher p3

Screw feeding multihead weigher is suitable for weighing the sticky material, such as chicken, pork, duck, fish, and beef and so on.

Screw Feeding Multihead Weigher Product

  • Special load cell with high precision and high standard
  • Intelligent multiple sampling stable mode, make weighing higher accurate
  • High speed staggered discharging function, effectively prevent blocking materials
  • CAN bus technology and with high integrated modular design
  • Screw feeding to replace the traditional vibrator feeding, it’s more suitable for sticky material
  • Stable actuator shell structure makes the hopper running more stable and higher accuracy
  • IP65 waterproof machine case, 60°discharge chute drop material faster

Option:

  • Drying device to prevent the electrical components from damage of humidity

 Model

 ATO-W4-14S 14 Heads

 Weighing Range

 10-1500g

 Accuracy

 x(0.5)

Max Speed

 50P/M

 Hopper Volume

2.5L

Control Panel

  9.7″ Touch Screen

 Options

 Dimple Plate/Timing Hopper/Printer/ Reject Device

 Driving System

  Step Motor

  Power Requirement

 220V/1500W/ 50/60Hz /10A

 Packing Dimension(mm)

 1750(L)X1130(w)X1450(H)

 Gross Weight

 500kg
