ATO-W4-12B Head Manual Belt Multihead Weigher
Application
Features
Specification
Application
It’s suitable for weighing large block, strip, and stem materials with poor fluidity, such as fish, noodles, shrimp and other aquatic products, meat products, medicinal materials, and other material.
Features
- High precision, high standard special load cells
- Intelligent multi-sampling stable mode, and the weighing is more accurate
- Concentrated discharge mode to ensure the relative concentration of materials and improve the running speed of the machine
- Intelligently customize the number of weighing trays to achieve double standards of weighing and counting
- Double row linear layout, easy to operate
- Belt-type open weighing tray design structure can effectively solve the feeding of sticky or bulky materials with poor fluidity
- Visualize LED signal light, clear the feeding direction and feeding area, and effectively identify the current status of the corresponding tray
- Easy detachable conveyor belt, easy to clean.
- HMI interface to facilitate self-learning and exchange of information
Specification
|
Model |
ATO-W4-12B 12 Heads |
ATO-W4 -14B 14 Heads |
|
Weighing Range |
10-6000g |
10-6000g |
|
Accuracy |
X（0.5） |
X（0.5） |
|
Max Speed |
30P/M |
35P/M |
|
Protection Class |
IP65 |
|
|
Weighing Belt Dimension |
300(L)x180(W) |
|
|
Control Panel |
10.1” Touch Screen |
|
|
Driving System |
Step Motor |
|
|
Power Requirement |
220V/800W/50/60Hz/3.6A |
|
|
Packing Dimension(mm) |
2200(L)x1200(W)x1160(H) |
2560(L)x1200(W)x1160(H) |
|
Gross Weight |
370kg |
450kg |
